Made in the USA
Portable Air Cleaner
Portable Air Cleaners, manufactured by Sentry Air Systems, are compact, self-contained, air filtration systems that are best utilized in filtering hazardous fumes, vapors, and particulates from the ambient air. Typically used in offices, hotel rooms, small warehouses, and locations where ducting and oversized ventilation cannot suffice, portable air cleaners are a necessity to eliminate high volumes of contaminants to protect users, applications, and the immediate environment.
200 Series
Model # SS-XXX-XXX
Unit Configurations Quick Compare
Additional Configurations
What is a Portable Air Cleaner?
A portable air cleaner is an air filtration unit that removes particulate, fumes, and bacteria, and does not produce a negative working environment as a by-product of its operation. While portable units come in large and small sizes, and are meant to be used in specific areas of a building, their effectiveness is more dependent of the filters that are used (such as HEPA).
How does a portable air cleaner work?
Where should you place your portable air cleaner?
The portable air cleaner should be placed in the room so that the air intake and outflow are not blocked by furniture, curtains, or room corners. While these air cleaning units work best when placed in a central spot, it is recommended to follow the manufacturer's instructions on placement and operation. In addition, some portable air cleaners are designed for tabletops, while others may be designed for the floor.
Is your application appropriate for an Ambient Air Cleaner?
Sentry Air Systems' portable air cleaners are designed and manufactured to accommodate a variety of applications making them the easiest air filtration system to fit your specific needs.
There are many applications that fit the use of a Portable Air Cleaner, typical uses include:
- Commercial Buildings
- Medical
- Small Offices
- Laboratories
- Residential
- Small Warehouses
Optional HEPA, ULPA, and charcoal filters are available for more demanding industrial ventilation system applications. However, in most cases, speaking with a subject matter expert to determine whether or not your application requires an ambient air cleaner is advisable.
Benefits of a Portable Air Cleaner
- Minimize employee exposure to contaminated air.
- Meet your legal obligations
- Heavy Duty Construction
- Low power consumption
- Reliable , low maintenance operation
- No permitting issues for venting outside (ie. EPA air sampling)
- Variable Speed Controller Included (115V only)
- Quiet Operation
- Sturdy Construction
- Long Filter Life
200 Series
Chemicals SS-200
Cabinet Dimensions:
- O.D: 10.5"L x 8"W x 10.75"H
Cabinet Material:
- 16 ga. carbon steel
Motor:
Fractional Horsepower
Total Weight:
Approx. 12 lbs.
Air Volume:
Up to 80 CFM
Electrical:
115/1/60, .3 amps
220/1/50, .2 amps
Sound Level:
Approx. 58 dba @ 3' from inlet
Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit
Patented Design:
U.S. PATENT #5,843,197
Particulate SS-225
Cabinet Dimensions:
- O.D: 10.5"L x 8"W x 10.75"H
Cabinet Material:
- 16 ga. carbon steel
Motor:
Fractional Horsepower
Total Weight:
Approx. 12 lbs.
Air Volume:
Up to 91 CFM
Electrical:
115/1/60, .46 amps
Sound Level:
Approx. 64 dba @ 3' from inlet
Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit
Patented Design:
U.S. PATENT #5,843,197
Cabinet Dimensions:
- O.D: 15.5"L x 13"W x 14.5"H
Cabinet Material:
- 16 ga. carbon steel w/ polyester epoxy coating on all surfaces
Motor:
Fractional Horsepower
Total Weight:
Approx. 40 lbs.
Electrical:
115/1/60, 2 amps
220/1/50, .75 amps
Sound Level:
61 to 66 dba (Blower Speed: Low to High)
Max Operating Temperature: Not to exceed 170 degrees Fahrenheit
Warranty:
Limited two-year warranty from date of shipment on defects due to materials or workmanship.
Patented Design:
U.S. PATENT #5,843,197
Chemicals SS-400
Cabinet Dimensions:
- 22.5"L x 20"W x 17.75"H
Weight:
50 lbs. to 110 lbs.
Cabinet Material:
16 ga. carbon steel
Air Volume:
Variable Speed Control Standard
700 CFM High, Down to 50 CFM Low
Electrical:
115/1/60, 2.5 amps
220/1/50 or 60, 1.5 amps
Sound Level:
60 dba @ 3 ft.
Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit
Patented Design:
U.S. PATENT #5,843,197
U.S. PATENT #8,353,745
Particulate SS-450
Cabinet Dimensions:
- 22.5"L x 20"W x 20"H
Cabinet Material:
- 16 ga. carbon steel
Total Weight:
62 lbs to 112 lbs
Motor:
Fractional Horsepower
Air Volume:
Variable Speed Control Standard
877 CFM High, Down to 0 CFM Low
Electrical:
115/1/60, 5.2 amps
Sound Level:
71 dba @ 3 ft.
Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit
Patented Design:
U.S. PATENT #5,843,197
U.S. PATENT #8,353,745
Base Unit Dimensions:
- O.D: 13.2"L x 13.1"W x 14.2"H
Chassis Material:
- 16 ga G90 Galvanized Steel
Total Weight:
Approx. 40 lbs.
Electrical:
115/1/60, 2 amps
8’ grounded power cord with NEMA 5-15P plug
Sound Level:
Approx. 69.5 dba @ 3' from inlet
Warranty:
Limited two-year warranty from date of shipment on defects due to materials or workmanship.
Quick Compare
200 Series
|
300 Series
|
400 Series
|
AirGuardian
|
|
|---|---|---|---|---|
| Cabinet Dimensions: | 10.5"L x 8"W x 10.75"H | 15.5"L x 13"W x 14.5"H | 22.5"L x 20"W x 17.75"H | 13.2"L x 13.1"W x 14.2"H |
| Weight: | Approx. 12 lbs. | Approx. 40 lbs. | Between 50 - 100 lbs | Approx. 40 lbs. |
| Electrical |
115/1/60, .3 amps 220/1/50, .2 amps |
115/1/60, 2 amps 220/1/50, .75 amps |
400 Series: 115/1/60, 2.5 amps 220/1/50, 1.5 amps 450 Series: 115/1/60, 5.2 amps |
115/1/60, 2 amps |
| Sound Level | Approx. 58 dba @ 3' from inlet | 61 to 66 dba (Blower Speed: Low to High) | 55 dba @ 3 ft. from hood inlet | Approx. 69.5 dba @ 3' from inlet |
Applications
- Commercial Buildings
- Medical
- Small Offices
- Laboratories
- Residential
- Small Warehouses
