High Flow Portable Fume Extractor

Portable Floor Sentry

Model # SS-400-PFS & Model # SS-450-PFS

Portable Fume Extractor
Loading the player...

The Portable Floor Sentry fume extractor is used as a respiratory safety control for a variety of industrial applications that require the capture and filtration of airborne contaminants and chemical fumes. This source-capture fume extractor features quiet operation, a powerful fan, a flame-retardant and self-supportive flex arm, and a variety of high-quality filtration media.

Typical applications for this unit include: welding fume control, chemical fume extraction, solvent and epoxy fume control, particulate extraction, powder filling, soldering, light grinding, clean room applications, and a variety of applications involving chemical fumes and dust.

Several filter media options are available for this unit and include: HEPA filtration [up to 99.97% efficient on particles 0.3 microns and larger, ASHRAE filtration [up to 95% efficient on particles 0.5 microns and larger], Activated Carbon, and specialty-blended filter media [i.e. Acid Gas, Mercury, Aldehyde, Ammonia]. The Portable Floor Sentry allows multiple filter media to be housed inside the filter chamber for applications that emit both particulate and fume.

Other unit features include a variable speed controller, portability handle, 360 degree swivel arm, simple and quick "no-tool" filter change, and optional accessories including a magnehelic gauge, digital hour counter, and quick change pre-filter.

A smaller model [SS-300-PFS] and larger model [SS-500-PFS-MP1] are also available.

University of Hawaii
(For SS-400-WFE)
"In our machine shop, we perform a number of operations including milling, lathing, welding and soldering/brazing. Most recently we were tasked with milling a bunch of 3/4" thick plate steel. The resulting smoke and smell from the cutting oil was overwhelming. After looking at several different manufacturers, it became obvious the SS-400-WFE portable air cleaner was far and beyond the one to get given its compact size & portability, low noise, good airflow, low power consumption, and versatility. After receiving our SS-400-WFE, I'm happy to report smoke and smell are things of the past. The SS-400-WFE completely eliminated both." -Mitch Pinkerton
Simplers Botanical
"Our 400-PFS is nothing short of a breath-saver, skin-saver, life-saver. We are a high volume essential oil company that, over the years, found employees having to deal with levels of atmospheric volatile oil compounds that was becoming intolerable. The 400-PFS has virtually removed the volatiles from our working environment. I cannot speak strongly enough of what this has done for the safety of our people. Totally recommended." - Matthew Persico
Portable Floor Sentry
Portable Floor Sentry
Portable Floor Sentry
Portable Floor Sentry
Portable Floor Sentry
Portable Floor Sentry
Specifications

SS-400-PFS

brochure
Cabinet Dimensions:
22.5"L x 20"W x 19.5"H
Arm
Dimensions:
6" Round x 72" Long fire retardant flex hose
Weight:
50 lbs to 100 lbs
Cabinet Material:
16 ga. carbon steel
Motor:
Fractional Horsepower
Available Filter
Efficiencies:
HEPA Filter - Up to 99.97% efficient on particles down to 0.3 microns in size.
ASHRAE Filter - Up to 95% efficient on particles down to 0.5 microns in size.
ULPA Filter - Up to 99.9995% efficient on particles down to 0.12 microns in size.
Activated Carbon & Specialty-Blended Filters - Efficiency varies per chemical.
Air Volume:
Variable Speed Control Standard on 115
700 CFM High, Down to 50 CFM Low
On/Off Toggle Switch Standard on 220
Electrical:
115/1/60, 2.5 amps
220/1/50, 1.5 amps
Sound Level:
Approx. 60 dba @ 3'
Warranty:
Limited two-year warranty from date of shipment on defects due to materials or workmanship.
Patented Design:
U.S. PATENT #5,843,197
U.S. PATENT #8,353,745

SS-450-PFS

brochure
Cabinet Dimensions:
22.5"L x 20"W x 19.5"H
Arm
Dimensions:
6" Round x 72" Long fire retardant flex hose
Weight:
62 lbs to 112 lbs.
Cabinet Material:
16 ga. carbon steel
Motor:
1.5 HP
Available Filter
Efficiencies:
HEPA Filter - Up to 99.97% efficient on particles down to 0.3 microns in size.
ASHRAE Filter - Up to 95% efficient on particles down to 0.5 microns in size.
ULPA Filter - Up to 99.9995% efficient on particles down to 0.12 microns in size.
Activated Carbon & Specialty-Blended Filters - Efficiency varies per chemical.
Air Volume:
Variable Speed Control Standard on 115
950 CFM High, Down to 50 CFM Low
On/Off Toggle Switch Standard on 220
Electrical:
115/1/60, 10.7 amps
220/1/50, 5.35 amps
Sound Level:
Approx. 72 dba @ 3'
Warranty:
Limited six-month warranty from date of shipment for the fan/motor assembly. Limited two-year warranty from date of shipment on defects to parts/assembly due to materials or workmanship.
Patented Design:
U.S. PATENT #5,843,197
U.S. PATENT #8,353,745

All specifications are nominal and subject to change without notice. Not intended for explosive or highly flammable applications. (i.e. when the Lower Flammability Limit is exceeded for any given chemical). Please consult the specific MSDS for questions regarding flammability limits.

Accessories

Quick Change Pre-Filter
SS-400-QCPF
Allows easy access to pre-filters.
Remote Control Box
SS-400-RCB
Controls unit operation remotely.
Magnehelic Gage
SS-400-MAG
Monitors filter saturation
Hour Counter
SS-000-HC
Displays hours unit has
been in operation.
REPLACEMENT
FILTERS

100 Series (Up to 80 CFM)
200 Series (Up to 100 CFM)
300 Series (Up to 350 CFM)
400 Series (Up to 700 CFM)
450 Series (Up to 950 CFM)
500 Series (Up to 1300 CFM)
Extractor Arms (Exhaust Hoses)
Accessories (For All Products)

Additional Configurations 400 Series - Up To 700 CFM
450 Series - Up To 950 CFM
